Bronze SDNR Globe Valve PN25 - Screwed BSPP Handwheel

The Bronze SDNR Globe Valve PN25 Screwed BSPP gives you precise throttling control with a built-in non-return function. The bronze body resists corrosion well. Furthermore, the SDNR design stops backflow without a separate check valve. This makes it a practical choice for steam and condensate return systems. For the full range, see our Globe Valves collection.

Six sizes are available from 1/2" to 2". The handwheel also gives straightforward manual control. Screwed BSPP ends make installation secure and simple.

Key Features of This Bronze SDNR Globe Valve PN25 BSPP

• Body material: Bronze — consequently giving corrosion resistance in demanding conditions
• Valve type: SDNR globe — also prevents backflow without a separate check valve
• Seat: Integral PTFE for reliable shut-off
• End connections: Screwed BSPP
• Operation: Handwheel for manual adjustment
• Pressure rating: PN25
• Temperature range: -20°C to +198°C
• Sizes available: 1/2", 3/4", 1", 1¼", 1½", 2"
• SKUs: V153604SDNR (1/2"), V153605SDNR (3/4"), V153606SDNR (1"), V153607SDNR (1¼"), V153608SDNR (1½"), V153609SDNR (2")
• Vendor: UTAM

Applications for a Bronze SDNR Globe Valve PN25 Screwed BSPP

This PN25 screwed BSPP bronze globe valve suits hot water recirculation, steam services, and condensate return lines. In addition, the SDNR function makes it useful where backflow is a risk. Moreover, the PTFE seat gives a reliable shut-off in process and general industrial applications. Always fit the valve in the correct flow direction as marked on the body.

Pressure and Temperature Ratings

This bronze SDNR globe valve carries a PN25 pressure rating. The temperature range is -20°C to +198°C. Consequently, it suits steam and high-temperature hot water systems. However, always check that the pressure and temperature in your system fall within these limits before specifying.

Selection Advice

Select the size that matches your pipe bore and BSPP thread. As a result, you get a secure fit without adaptors. If you need a globe valve without the SDNR function, see the full Globe Valves range for alternatives.
