Brass Ball Valve With Fixed Extended Neck

The Brass Ball Valve with Fixed Extended Neck is built for installations where valve accessibility and insulation clearance are critical. The fixed extended neck design allows easy operation when valves are located behind cladding, panelling, or insulation.

Its nickel-plated brass body ensures long-lasting protection against corrosion and mechanical wear, making it ideal for heating, plumbing, and low-pressure industrial systems.

Technical Data:

• Body Material: Nickel-plated brass
• Connection Type: BSPP female ends
• Extension Type: Fixed, integral neck design
• Pressure Rating: Rated PN40 ¼ to 1, PN25 1¼ to 2, PN16 2½ to 4
• Temperature Range: 20°C to +110°C
• Flow Design: Full-bore, quarter-turn shut-off

Product Highlights:

• Extended neck allows easy handle access after installation
• Strong, durable brass body
• Smooth quarter-turn operation
• Suitable for a wide range of media

Applications: Hot and cold water systems, heating systems, and industrial control panels.
