Cast Iron Knife Gate Valve - Handwheel Operated Wafer PN10

SKU V580511
£569.77
Excl. tax:  £474.81
£569.77
Excl. tax:  £474.81
Size:
Cast Iron Knife Gate Valve - Handwheel Operated Wafer PN10 for efficient fluid control in industrial pipelines. Cast Iron Knife Gate Valve - Handwheel Operated Wafer PN10 specifications and features sheet. Technical data sheet for Cast Iron Knife Gate Valve - Handwheel Operated Wafer PN10 products.
Cast Iron Knife Gate Valve - Handwheel Operated Wafer PN10 for efficient fluid control in industrial pipelines. Cast Iron Knife Gate Valve - Handwheel Operated Wafer PN10 specifications and features sheet. Technical data sheet for Cast Iron Knife Gate Valve - Handwheel Operated Wafer PN10 products.

This Cast Iron Knife Gate Valve is designed for reliable unidirectional isolation in pipelines handling solids, slurries, or viscous media. Featuring a space-saving wafer design, this valve is clamped securely between flanges to provide a compact and efficient solution for industrial fluid control.

  • Durable Construction: Built with a robust cast iron body and a stainless steel knife for long-lasting performance in demanding environments.
  • Manual Control: Equipped with a handwheel actuator for intuitive and smooth manual operation, even when the system is under load.
  • Efficient Flow: The straight-through full bore design minimises pressure drop and prevents the build-up of solids.
  • Resilient Sealing: Features an EPDM seat to ensure a tight seal and dependable shut-off for wastewater and effluent applications.

Ideal for wastewater treatment, solids transport, and industrial effluent systems, this valve should be installed between PN10 flanges with the flow oriented according to the body markings. It offers an economical and dependable manual solution for modern pipeline management.

Body Material Cast Iron Body, Stainless Steel Knife
Valve Type Knife gate, unidirectional
End Connection Wafer PN10 (between flanges)
Seat EPDM
Actuation Handwheel
Pressure Rating Rated PN10 2" to 6", PN8 8", PN7 10", PN6 12" & 14", PN5 16"
Temperature Range 35°C to +120 °C
Flow Pattern Straight-through full bore
