Stainless Steel Check Valve Screwed NPT 6000psi

This version of the stainless steel 6000psi check valve uses NPT screwed ends the US standard for tapered thread piping. It brings highpressure capability and stainlesssteel durability into compact installations with standard NPT connections.

Technical Data:

• Body Material: Stainless steel (316/CF8M) suited for highpressure and aggressive media. Stainless Steel Spring & Disc
• Connection Type: NPT (National Pipe Taper) screwed ends
• Pressure Rating: Up to 6000psi (~414bar) depending on size and rating.
• Temperature Range: -34°C to +135°C
• Mechanism: Disc or ball check design for minimal pressure drop and reliable shutoff.
• Seat Material: Buna N Seat

Key Features:

• NPT threading means compatibility with Americanstyle installations.
• Highpressure rating makes it suitable for demanding hydraulic or process applications.
• Stainless steel construction adds corrosion resistance and durability for long service.

Typical Applications:
Oil & gas highpressure feed, hydraulic control systems, test rigs, instrumentation lines and compressed fluid systems requiring premium nonreturn protection.
